The description of Stadium Tent Tensile Membrane Structure
| Products name | System integration/Automatic Production Line | Place of Origin | Jiangsu, China |
| Frame material | Q235 Steel | Cover material | PVDF/PTFE/ETFE |
| Design Style | Modern | Yarn count(yarn/cn) | 12/12/yarn/cm |
| Type | membrane structure | Weave style | Woven fabric P 2/2 |
| Feature | Eco Friendly, Fire Resistant | Total weight (g/㎡) | 1100G/㎡ |
| Warranty | More Than 5 Years | Total thickness(mm) | 0.83 ± 0.02 mm |
| Color | White or customized |
Guarantee year
|
10~30 years |
| Fire rating | DIN4102B1, GB 8621B1 |
Certificate |
CE TUV SGS |
| Wind Resistance | 120km/h(lever 12) | Application | Sport |
| Advantage1 | Thermal Insulation | Feature | Eco Friendly, Fire Resistant |
| Advantage 2 | Easy Installation | After-sale Service | Online Technical Support, Onsite Installation, Onsite Inspection |
| Size | Customiezd | Project Solution Capability | graphic design, 3D model design, total solution for projects, Cross Categories Consolidation |
Comparison of PVDF and PVC
Property
|
1100 g/m² PVDF Membrane
|
Standard PVC Membrane (600 g/m²)
|
|---|---|---|
Thickness
|
0.85 mm
|
0.45–0.50 mm
|
Fire Rating
|
B1
|
B2
|
UV Resistance
|
>10 years
|
3–5 years
|
Tensile Strength
|
Warp: 3500 N/5cm, Weft: 3000 N/5cm
|
Warp: 2000 N/5cm, Weft: 1800 N/5cm
|
Lifespan
|
10+ years
|
5–7 years
|
Heat Insulation
|
High
|
Moderate
|
Waterproof
|
100%
|
95–98%
|
Advantages of Stadium Tent Tensile Membrane Structure
1. Frame Material: High reinforced Q235 steel + Epoxy zinc-rich primer; Anti-corrosion & rust; long-term structural stability; lifespan >30 years.
2. Roof Fabric: 1100 g/m² PVDF tensile membrane fabric; Thick, durable membrane (~0.85mm) providing strong structural integrity.
3. Waterproofing: PVDF coating, 100% waterproof; Protects stored goods, prevents water ingress, suitable for warehouses, carports, event spaces.
4. Fire Resistance: DIN4102B1, GB 8621B1; Flame retardant; meets international fire safety standards
5. UV Resistance: PVDF membrane UV stabilized; Reduces degradation from sunlight; suitable for outdoor exposure
6. Thermal Performance: Heat insulation; Reduces internal temperature by 5–10°C compared to ambient (typical tensile membrane performance)
why choose us
Professional manufacturer of aluminium clear span tent for over 10 years
why choose our Stadium Tent Tensile Membrane Structure
| Advantage | Data / Proof | Icon / Visual Suggestion |
|---|---|---|
| Experience | 10+ years, 500+ projects globally | 🌍 World map with project pins |
| Customization | Designs for warehouses, stadiums, carports | ✏️ Custom blueprint icon |
| Equipment | CNC & 3D membrane machines | ⚙️ Machinery illustration |
| Certification | ISO9001, CE, SGS | ✅ Certificate badge icon |
| After-Sales | 24/7 support, spare parts | 🛠️ Wrench & headset icon |
| Durability | PVDF membrane 10+ yrs, steel frame 30+ yrs | 🏗️ Timeline chart of lifespan |
FAQ
Q1: Where is your factory?
A1: Our factory is located in Jiangsu Province, China.
Q2: What is your payment method?
A2: Our standard payment terms are: 30% deposit by T/T to start production, with the balance paid by T/T before shipment.
Q3: Do you accept mixed loading in one container?
A3: Yes. Especially during periods of high sea freight costs, we can provide professional mixed loading solutions to help clients reduce shipping expenses.
Q4: What is the minimum order quantity (MOQ)?
A4: The minimum order quantity for our tents is 25 square meters.
Q5: Are you a factory or a trading company?
A5: We are a manufacturer, which allows us to offer competitive prices while ensuring high-quality products.
Q6: What size tent is necessary for my special event?
A6: Tent size depends on the intended use. For banquet seating with round tables, allow approximately 1.3 square meters per person. Please leave your contact information, and our team will provide a customized tent solution tailored to your event.
